©FUTABA CORPORATION 2018, 5 (2)
Compliance Information Statement
(for U.S.A.)
This device, trade name Futaba Corporation of America, model number R314SB, complies
with part15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
(3) This module meets the requirements for a mobile device that may be used at separation
distances of more than 20cm from human body.
To meet the RF exposure requirements of the FCC this device shall not be co-located with
another transmitting device.
The responsible party of this device compliance is:
FUTABA Corporation of America
2681 Wall Triana Hwy Huntsville, AL 35824, U.S.A.
Phone:1-256-461-9399 FAX:1-256-461-1059 E-mail: service@futabaUSA.com
R314SB Specifications:
R314SB Specifications:
(
T-FHSS
system,
S.BUS2
, 4-channel receiver)
• Receiving on 2.4GHz band
• System:
T-FHSS
system
At Normal/High speed mode (auto detection)
•
Power requirement Rated voltage: 4.8V-7.4V / Usable voltage: 3.5-8.4V
• F/S and Battery F/S function:It is set according to the transmitter used.
• Battery F/S voltage: Set it with the transmitter arbitrarily.
• Size: 1.38x0.91x0.33” (35.1x23.2x8.5mm)
• Weight: 0.23oz. (6.6g)
2
5HFHLYHU
+8%
7HPSHUDWXUH
VHQVRU
530VHQVRU
9ROWDJHVHQVRU
6ZLWFK
%DWWHU\
7HOHPHWU\VHQVRUV
2SWLRQ
6WHHULQJVHUYR
7KURWWOHVHUYR
&+
&+
Collectmanytelemetry
sensorsbyHUBandconnect
themtoS.BUS2port.
6%86
&+
,WFRQQHFWVZLWKSRUWZKLFKLVQRWXVHGك
:KHQDOOWKHSRUWVDUHXVHGFRQQHFW
DEDWWHU\XVLQJ+8%RU<KDUQHVV
The Example of Connection
