FUTABA Sky Leaf Samba f User Manual

12
Ŕ
Ŕ
Ŕ
Ŕř
ŔŘ
ŔŚ
Ŕś
ŔŜ
RudderLinkage
ElevatorLinkage
Fuselage
Rudder
● PrepareElevatorservowith
a400mmExtension.
● PrepareRudderservowith
a500mmExtension.
EXTENSION
● Placetheelevatorandrudderservosin
positionanduseadrilltomakethestarter
holeformountingholesforyourservosinto
thefuselage.
● Screwtheservoarmplatetothetopofthestock
servoarm.(ElevatorservoandRudderservo)
● Useyourradiotocenter
yourservos.Attachaservo
armtoeachservosothat
thearmisverticalposition.
● InstalltheElevatorServousingthe
screwsprovidedwithyourservo.
● Servoleadwiresarerouted
thoughthecenterpart
throughthefuselageinterior.
● InstalltheRudderServousingthe
screwsprovidedwithyourservo.
● Adjustthelengthoftherod
sothatthesurfaceisneutral
andsecuretheballlink.
● Usetheinside
hole.
● Usetheinside
hole.
M2Nut
BallLink
M2 × 10Hexheadbolt
M2 × 5TappingScrew
ServoArm
ServoHorn
M2 × 12Hexheadbolt
!Thetheraisedballlinkon
theservoside.
!Thetheraisedballlinkon
theservoside.
M2Nut
M2Washer
RudderRod
ElevatorRod
BallLink
M2 × 10Hexheadbolt
BallLink
M2 × 10Hexheadbolt M2 × 12Hexheadbolt
RaisedBallLink
M2 × 12Hexheadbolt
M2Nut
M2Washer
M2Nut
M2Washer
BallLink
M2 × 10Hexheadbolt
