System Lockout Screen - When entering the menu screens,
if there is a lockout code enabled this screen will appear. You
must enter the system password to be able to go any further
into the menu screens. If this option is not needed it may be
disabled in the installation menu. Password is factory set to
1000
Filtering - Changing the ltering rate can help to cure any
jumpy behaviour of the receiver. The best setting is the fastest
setting with the least amount of interruptions.
Laser Receiver Deadband - Is the amount of allowable on-
grade tolerance. The range is 1mm to 30mm at 1mm steps.
When the receiver is receiving the laser light in the on-grade
position, the valves will not activate until the deadband range
is passed. If the on-grade deadband is set to 10mm, the
valves will not be activated until the receiver readings are be-
yond 5mm in either direction.
Horn - Sets the function of the internal beeper. Off: disables
the internal beeper. Alert: sets the beeper to grade alarm
mode. When in automatic, if there is no on-grade indication for
6 seconds the alarm will sound. Indicate: sets the beeper to
indicate mode, where the beeper will act as a detector. If the
beam is too high you get a double beep, too low a single beep
and on grade a solid beep.
Height Adjustment - By setting the height adjustment op-
tion to “ON”, the off-set knob is enabled and the user has the
ability to have an adjustable ‘on grade’ which is displayed on
the LCD. If the Height adjustment is off or Height set to “0”,
the off-set knob is disabled and the ‘Real Time’ blade position
is displayed on the LCD.
Unit selection - Sets for 3 different units: Millimeters, Inches
(decimal inches) or Feet (10th of a foot).
Latec Info Screen - The nal screen in the menu displays
manufacturer info: name and phone number. Outside of North
America, dial +01.519.235.4585.
Note:
To access the Installation Menu , press the Menu
and Power button in UNISON while the LATEC info
screen is displayed.
-> Return
Filtering Next
20mm grade Next
Next
Next
Change Next
5192354585 Next
Pass
|EFFF| 0000
FAST -I - - - - Slow
Lsr Rec. deadbnd
Horn Off
Height Adj ON
Use millimeters
LATEC Instr. Inc
Page 6
