Future light EYE-7 - Overview

00073815.DOC, Version 1.1 30/47
Overview
(1) Projector head
(2) LED
(3) Yoke
(4) Base
(5) Rubber foot
(6) Wireless indicator
(7) Safety eyelet
(8) LCD display
(9) Microphone
(10) Arrow button left
(11) Arrow button down
(12) Enter button
(13) Arrow button up
(14) Arrow button right
(15) Fan
(16) Power input
(17) Fuse holder
(18) Power output
(19) Power switch
(20) 3-pin DMX output socket
(21) 3-pin DMX input socket
(22) Housing screw
1
2
3
4
5 6 7 8 9
11 12 13 14
10
21 22
15
16 17 18 19 20
