00073815.DOC, Version 1.1 36/47
DMX-protocol
Mode/Channel Decimal Hexad. Percentage S/F Feature
St. Ex. 1 Ex. 2
1 1 1
Horizontal movement (PAN)
0 255 00 FF 0% 100% F Push slider up in order to move the head
horizontally (PAN). Gradual head adjustment
from one end of the slider to the other (0-255,
128-center). The head can be stopped at any
position you wish.
2 2
PAN-movement with 16-bit resolution
0 255 00 FF 0% 100% F Fine indexing
2 3 3
Vertical movement (Tilt)
0 255 00 FF 0% 100% F Push slider up in order to move the head
vertically (TILT). Gradual head adjustment from
one end of the slider to the other (0-255, 128-
center). The head can be stopped at any
position you wish.
4 4
TILT-movement with 16-bit resolution
0 255 00 FF 0% 100% F Fine indexing
3 5 5
PAN/TILT speed
0 255 00 FF 0% 100% F Decreasing speed
6
PAN/TILT function
0 15 00 0F 0% 6% S Normal
16 31 10 1F 6% 12% S Blackout at PAN/TILT-movement
32 255 20 FF 13% 100% S No function
4 6 7
Shutter, strobe function
0 15 00 0F 0% 6% S Normal Shutter Functions
16 31 10 1F 6% 12% S Opening pulse-effect
32 47 20 2F 13% 18% S Closing pulse-effect
48 63 30 3F 19% 25% S Random strobe-effect
64 255 40 FF 25% 100% S No function
5 7 8
Shutter, strobe
Normal Shutter Functions
0 31 00 1F 0% 12% S Close
32 223 20 DF 13% 87% F Strobe-effect with increasing speed
224 255 E0 FF 88% 100% S Open
Opening pulse-effect
0 31 00 1F 0% 12% S Close
32 223 20 DF 13% 87% F Pulse-effect with increasing speed
224 255 E0 FF 88% 100% S Open
Closing pulse-effect
0 31 00 1F 0% 12% S Close
32 223 20 DF 13% 87% F Pulse-effect with increasing speed
224 255 E0 FF 88% 100% S Open
Random strobe-effect
0 31 00 1F 0% 12% S Close
32 223 20 DF 13% 87% F Strobe-effect with increasing speed
224 255 E0 FF 88% 100% S Open
