Control-channel 5 - Colour-wheel 2
Linear colour change following the movement of the slider.
In this way you can stop the colour-wheel in any position.
Decimal Hexad. Percentage S/F Feature
0 15 00 0F 0% 6% S Open / white
16 31 10 1F 6% 12% S Red
32 47 20 2F 13% 18% S Light blue
48 63 30 3F 19% 25% S Pink
64 79 40 4F 25% 31% S Dark yellow
80 95 50 5F 31% 37% S Correction-filter 3,200 K
96 111 60 6F 38% 44% S Correction-filter 5,600 K
112 127 70 7F 44% 50% S UV
128 187 80 BB 50% 73% F Forwards rainbow effect with decreasing speed
188 193 BC C1 74% 76% S No rotation
194 255 C2 FF 76% 100% F Backwards rainbow effect with increasing speed
Control-channel 6 - Rotating gobo-wheel, gobo shake
Decimal Hexad. Percentage S/F Feature
0 9 00 09 0% 4% S Open
10 19 0A 13 4% 7% S Rot. gobo 1
20 29 14 1D 8% 11% S Rot. gobo 2
30 39 1E 27 12% 15% S Rot. gobo 3
40 49 28 31 16% 19% S Rot. gobo 4
50 59 32 3B 20% 23% S Rot. gobo 5
60 69 3C 45 24% 27% S Rot. gobo 6
70 89 46 59 27% 35% F Gobo 1 shake with increasing speed
90 109 5A 6D 35% 43% F Gobo 2 shake with increasing speed
110 129 6E 81 43% 51% F Gobo 3 shake with increasing speed
130 149 82 95 51% 58% F Gobo 4 shake with increasing speed
150 169 96 A9 59% 66% F Gobo 5 shake with increasing speed
170 189 AA BD 67% 74% F Gobo 6 shake with increasing speed
190 255 BE FF 75% 100% F Cont. gobo-wheel rotation with increasing speed
Control-channel 7 - Rotating gobo index, gobo rotation
Decimal Hexad. Percentage S/F Feature
0 127 00 7F 0% 50% S Gobo indexing
128 187 80 BB 50% 73% F Forwards gobo rotation with decreasing speed
188 193 BC C1 74% 76% S No rotation
194 255 C2 FF 76% 100% F Backwards gobo rotation with increasing speed
