TECHNICAL SPECIFICATIONS
Power supply: 230 V AC, 50 Hz ~
Power consumption: 1,000 W
DMX-control-channels: 17
DMX-512-connection: 3-pin XLR
Flash-rate: 13 Hz
Colour-wheel 1: 7 dichroic + white
Colour-wheel 2: 4 dichroic, 2 correction filters, UV-filter + white
Static gobo-wheel: 7 gobos and open
Rotating gobo-wheel: 6 gobos and open
Outside diameter of the gobos: 27 mm
Image diameter of the gobos: 23 mm
Maximum PAN-movement 630°: in 3.5 s
Maximum TILT-movement 265°: in 2.5 s
Length of base (including handles): 500 mm
Width of yoke: 390 mm
Height (head horizontal): 540 mm
Weight (net): 28.8 kg
Maximum ambient temperature T
a
:
45° C
Maximum housing temperature T
B
(steady state):
80° C
Min.distance from flammable surfaces: 0.5 m
Min.distance to lighted object: 0.5 m
Fuse: T 8 A, 250 V
Accessory:
GE CSR 700/2 72V/700W G-22 1000h No. 89105000
PHILIPS MSR700/2 72V/700W G-22 7200K No. 89105016
FUTURELIGHT CP-240 controller No. 51834265
FUTURELIGHT CP-256/64 controller 16bit No. 51834288
FUTURELIGHT CP-512/64 controller 16bit No. 51834295
Wizard-512 USB DMX-Software + Interface No. 51860102
Wizard-1024 USB DMX-Software + Interface No. 51860110
FUTURELIGHT DES-3 DMX-terminator 3-pin No. 51834001
Flightcase for 2x PHS/PHW-700+reel-board No. 51836865
Please note: Every information is subject to change without prior notice. 14.11.2006 ©
