51838328_V_1_0.DOC
49/119
Control-channel 11 - Iris
Decimal Hexad. Percentage S/F Feature
0 191 00 BF 0% 75% F Max. diameter to Min. diameter
192 223 C0 DF 75% 87% F Pulse opening with decreasing speed
224 255 E0 FF 88% 100% F Pulse closing with increasing speed
Control-channel 12 - Shutter, strobe
Decimal Hexad. Percentage S/F Feature
0 31 00 1F 0% 12% S Shutter closed
32 63 20 3F 13% 25% S No function (shutter open)
64 95 40 5F 25% 37% F Strobe-effect with increasing speed
96 127 60 7F 38% 50% S No function (shutter open)
128 159 80 9F 50% 62% F Pulse-effect in sequences
160 191 A0 BF 63% 75% S No function (shutter open)
192 223 C0 DF 75% 87% F Random strobe-effect with increasing speed
224 255 E0 FF 88% 100% S No function (shutter open)
Control-channel 13 - Dimmer intensity
Decimal Hexad. Percentage S/F Feature
0 255 00 FF 0% 100% F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 14 - Frost
Decimal Hexad. Percentage S/F Feature
0 191 00 BF 0% 75% F Frost from 100 to 0 %
192 223 C0 DF 75% 87% F Pulse opening with decreasing speed
224 255 E0 FF 88% 100% F Pulse closing with increasing speed
Control-channel 15 - Switching the lamp, Reset, internal programs
Decimal Hexad. Percentage S/F Feature
0 31 00 1F 0% 12% S Normal colour-change
32 63 20 3F 13% 25% S Colour-change at every position
64 79 40 4F 25% 31% S Lamp on
80 95 50 5F 31% 37% S Reset
96 111 60 6F 38% 44% S Internal program 1
112 127 70 7F 44% 50% S Internal program 2
128 143 80 8F 50% 56% S Internal program 3
144 159 90 9F 56% 62% S Internal program 4
160 175 A0 AF 63% 69% S Internal program 5
176 191 B0 BF 69% 75% S Internal program 6
192 207 C0 CF 75% 81% S Internal program 7
208 223 D0 DF 82% 87% S Internal program 8
224 239 E0 EF 88% 94% S Lamp off
240 255 F0 FF 94% 100% S No function
Control-channel 16 - Pan-movement with 16 Bit-resolution
Control-channel 17 - Tilt-movement with 16 Bit-resolution
