Motor
- 6 high quality stepper motors controlled by microprocessors
Electronics
- Digital serial input DMX-512
- 10 control-channels (full 16 bit protocol):
Channel 1: Horizontal mirror-movement 8 bit
Channel 2: Vertical mirror-movement 8bit
Channel 3: Fine Horizontal mirror-movement 16 bit
Channel 4: Fine Vertical mirror-movement 16 bit
Channel 5: Pan/Tilt speed
Channel 6: Fan speed, On/Off lamp, reset
Channel 7: Colours
Channel 8: Shutter, Strobe, Gobos
Channel 9: Dimmer, Conversion filters, Frost, Rotating prism
Channel 10: Prism rotation
Housing
- Easy access to lamp and main components thanks to large opening cover and the projector‘s modular
construction.
Dimensions
- L x W x H: 550 x 240 x 210 mm
Weight
SC - 530: 17,5kg
SC - 570: 19kg
10. Maintenance and cleaning
It is absolutely essential that the projector is kept clean and that dust, dirt and smoke-fluid residues must not
build up on or within the projector. Otherwise, the projector‘s light-output will be significantly reduced. Regular
cleaning will not only ensure the maximum light-output, but will also allow the projector to function reliably
throughout its life.
A soft lint-free cloth moistened with any good glass cleaning fluid is recommended, under no circumstances
should alcohol or solvents be used!
DANGER !
Disconnect from the mains before starting any
maintenance work
The front mirror and objective lens will require weekly cleaning as smoke-fluid tends to building up residues,
reducing the light-output very quickly. The cooling-fan should be cleaned monthly.
The gobos may be cleaned with a soft brush. The interior of the projector should be cleaned at least
annually using a vacuum-cleaner or an air-jet.
The dichroic colour-filters, the gobo-wheel and the internal lenses should be cleaned monthly.
To ensure a proper function of the gobo-wheel, we recommend lubrication in six month intervals. The
quantity of oil must not be excessive in order to avoid that oil runs out when the gobo-wheel rotates.
11. Appendix
We hope you will enjoy your SC-530/SC-570. We can assure you that you will enjoy this device for years if you
follow the instructions given in this manual.
Should you have further questions, do not hesitate to contact your local dealer.
© 3/99
