24
0 Open / white
10 Turquoise
21 Red
32 Cyan
42 Green
53 Magenta
64 Light Blue
74 Yellow
85 Green
96 Pink
106 Blue
117 Orange
128 - 190 Forwards rainbow effect from fast to slow
191 - 192 No rotation
193 - 255 Backwards rainbow effect from slow to fast
4.1.8 Channel 8 - Gobos
0 Closed
1 - 45 Dimmer
46 - 63 Full open position
64 - 127 Strobo effect slow to fast (max 8 FPS)
128 - 140 Closed in reverse position
141 - 153 Gobo (dichro) 1
154 - 166 Gobo 2
167 - 179 Gobo 3
180 - 191 Gobo 4
192 - 204 Gobo 5
205 - 217 Gobo 6
218 - 230 Gobo 7
231 - 243 Gobo 8
244 - 255 Gobo 9
4.1.9 Channel 9 - Dimmer, frost, 3200°and 5600°K CTF, 3 facet rot. prism :
0 - Closed
1 - 63 Soft slow dimmer
64 - 95 Open position (hole)
96 - 127 Frost filter
128 - 159 Rotating 3-facet prisma
160 - 191 3200°K CTF
192 - 255 5600°K CTF
4.1.10 Channel 10 - 3 facet prisma rotation control :
0 No rotation
1 - 126 Forwards rotation from fast to slow
127 - 128 No rotation
129 - 255 Backwards rotation from slow to fast
4.2 Function of the control channels - 8 bit protocol:
For using of CP-64 SC5 controller:
