FutureLogic PSA-66-ST2RU - GEN2 Printer Reference Points for Cleaning; GEN3 Evolution Printer Reference Points for Cleaning

Printer Cleaning Guide
(GEN2™, GEN2 Universal™, and GEN3 Evolution® Printers)
 2010 – 2012 FutureLogic, Incorporated. All Rights Reserved. PUBN Page 3 11/14/2012
MNL-000054 REV.D
GEN2 Universal / GEN2 Printer – Reference Points for Procedures
GEN3 Evolution Printer – Reference Points for Procedures
Platen Roller
Print Head
Main Release Lever
Presenter Rollers
Printer Open Sensor
Ticket Taken Sensor
Pinch Roller
Platen Roller
Print Head
Main Release Lever
Pinch Roller
Printer Open Sensor
Ticket Taken Sensor
Presenter Rollers
