FUXTEC FX-LB126 - Overview of the Device

Original User Manual FUXTEC petrol leaf vacuum cleaner / blower FX-LBS126 / FX-LB126_rev05
11
8. Overview of the device
1. Spark plug
2. On/off switch
3. Throttle lever
4. Air filter cover
5th choke
6. Tank with lid
7. Pull starter
8. Lower handle
9. Two-piece blowpipe
10. Two-part suction pipe
11. Bent intake pipe
12. Leaf bag
13. Air intake grille lock
14. Chopper claw
15. Air intake grille
Leaf blower
Leaf Vacuum
