8. Overview of the device
1.Engine
2. Main tube with throttle
handle
3. Intermediate pipe
4. End pipe (1)
5. End pipe (2)
6. Throttle lever/grip
7. Corrugated pipe
8. Mixing container
9. Mounting clamps
10. Pull starter
11.fuel cap
12th choke
13. air filter box
14. spark plug
1
2
5
4
3
6
7
8
9
10
11
12
13
14
