WARNING: Always wear eye protection with side
shields marked to comply with ANSI Z87.1. Failure to
do so could result in objects being thrown into your
eyes resulting in possible serious injury.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts.
Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged
by their use. Use clean cloths to remove dirt, dust, oil,
grease, etc.
WARNING: Do not at any time let brake fluids,
gasoline, petroleum-based products, penetrating oils,
etc., come in contact with plastic parts. Chemicals
can damage, weaken, or destroy plastic which can
result in serious personal injury.
Periodically check all nuts and bolts for proper
tightness to ensure safe operation of the mower.
Remove any build-up of grass and leaves on or
around the motor cover. Wipe the mower clean with a
dry cloth occasionally. Do not use water.
LUBRICATION
All of the bearings in this product are lubricated with a
sufficient amount of high grade lubricant for the life of
the unit under normal operating conditions. Therefore,
no further bearing lubrication is required.
REPLACING THE BLADE (FIG.20 & 21)
WARNING: Always protect hands by wearing heavy
gloves and/or wrapping the cutting edges of the blade
with rags and other material when performing blade
maintenance. Contact with the blade could result in
serious personal injury.
Stop the motor and remove the key. Allow blade to
come to a complete stop.
Remove the battery pack.
Turn the mower on its side.
While wearing leather padded gloves, wedge a block
of wood between the blade and the mower deck in
order to prevent the blade from turning when the nut
is being removed.
Using a wrench or socket, loosen the blade nut (1)
and remove the blade (2). Turn the nut “COUNTER-
CLOCKWISE” to loosen it and “CLOCKWISE” to
tighten it.
Remove the blade nut (1), the blade (2) and fixed shaft
sleeve (3).
To re-install the blade, position the blade with the
cutting edges toward the mower. Assemble the fixed
shaft sleeve, blade, blade nut as shown. Using a
socket or wrench, turn the blade nut "CLOCKWISE” in
order to secure the blade.
NOTE: Make certain all parts are replaced in the exact
order in which they were removed.
STORING THE MOWER
Remove the batteries and key and store in a secure
location out of the reach of children.
Before storage, wipe any dirt or debris from the
battery area.
Turn mower on its side and clean grass clippings that
have accumulated on the underside of the mower
deck.
Wipe the mower clean with a dry cloth.
Check all nuts, bolts, knobs, screws, fasteners, etc.,
for tightness.
Inspect moving parts for damage, breakage, and
wear. Have repairs made on any damaged or missing
parts. Check blade for damage, uneven, or excessive
wear and replace blade if these conditions exist.
Store mower indoors in a clean, dry place out of the
reach of children.
Do not store near corrosive materials such as fertilizer
or rock salt.
TECHNICAL SPECIFICATION
Voltage 2x18V DC
No load speed 2900min
-1
No load running time 50min
(2 x 4Ah Battery)
Cutting diameter 460mm
Height adjustments 6 positions
(30-80mm)
Motor type Brushless motor
Collection capacity 70L
Front wheel size 8”
Rear wheel size 11”
Sound pressure level L
pA
???dB(A)
k=3dB(A
Sound power level L
WA
???dB(A)
k=3dB(A
Vibration level ???m/s
2
K=1.5m/s
2
