G.T. Attuatori GTX Series User Manual

ATTUATORI .
- PNEUMATIC ACTUATORS AND ACCESSORIES -
UsermanING ISSUE .10 March 2004
GT ATTUATORI S.r.l. REA MI 1558400 FAX (02) 90390368
V.le Europa 17 - 20090 Cusago Partita IVA e Cod.Fisc.12449540157 TEL (02) 90390322
Milan - ITALY- E-mail g.trevisan@iol.it
www.gtrevisan.it
PAG. 19 OF 20
INSTALLATION
OPERATION &
MAINTENANCE MANUAL
15.0 SAFETY INSTRUCTIONS
15.1 - Pneumatic actuators of GTX seris have breen planned and manufactured in accordance with
ATEX 94/9/CE Standard, Group II, category 2 GD, with reference to the Norm UNI EN 1127-1 and UNI EN 13463-1
15.2 - Marking
II 2 GD c T 110° C Tech. File N° 2003/01
15. 3 - Matking description
II
2
GD
c
T 110°C
Tech. File N° 2003/1
Marking in conformity with applicable European Directives
Marking in conformity with Directive 94/9/CE and to related technical norms
Group II (surface)
Device of category 2
Explosive atmosphere with presence of gas, vapours, fogs and dusts
Manufactoring safety
Maximum surface temperature
Tecnical brochure number
16.0 DANGEROUS AREAS
Dangeruos area
Installation category in accordance
with ATEX 94/9/CE Directive
Gas, fogs, vapours and dusts Zone 1/21 2 GD
Gas, fogs, vapours and dusts Zone 2/22 3 GD
16. 1 - Pneumatic actuator suitability to installation place.
In case of use in areas with explosion danger, must be verified that the actuator is suitable to zone classification
and to inflammables peculiarity present on the plant.
Safety fundamental requirements against explosion risk into classified areas are fixed by European Directives
94/9/CE dated Mach 23, 1994 (for devices) and 1999/92/CE dated December 1999 (for plants).
16. 2 - Places with presence of gas, inflammable fogs, vapours and dusts.
Classification standard of explosion risk areas are indicated by EN 60079-10 Norm (Classification of dangerous
places for gas presence) and EN 550281-3 (Classification of dangerous places in which may be present combustible
dusts).
Based on these technical and lawgiving instructions, pneumatic actuator choice must consider following
factors:
- Plant type
- Zone classification: 0, 1, 2, 20, 21, 22 (for which are suitable devices respectively of category 1, 2, 3)
- Features of Inflammable substances present disguised as gases, vapours or fogs and layer of dust.
- Subgroup; IIA, IIB, IIC.
- Temperature class: T6 (defines gases ignition temperature)
- T (maximum superface temperature)
