ATTUATORI .
- PNEUMATIC ACTUATORS AND ACCESSORIES -
UsermanING ISSUE .10 March 2004
GT ATTUATORI S.r.l. REA MI 1558400 FAX (02) 90390368
V.le Europa 17 - 20090 Cusago Partita IVA e Cod.Fisc.12449540157 TEL (02) 90390322
Milan - ITALY- E-mail g.trevisan@iol.it
www.gtrevisan.it
PAG. 2 OF 20
INSTALLATION
OPERATION &
MAINTENANCE MANUAL
TABLE OF CONTENT
PAG.
1.0 INTRODUCTION 3
2.0 STORAGE 3
3.0 OPERATIONAL CHARACTERISTICS 3
4.0 ACTUATOR INSTALLATION 4
5.0 DISASSEMBLY PROCEDURE 7
6.0 RE-ASSEMBLY PROCEDURE 8
7.0 SPRING CARTRIDGES INSTALLATION 10
8.0 SOLENOID VALVES CHARACTERISTICS 12
9.0 SOLENOID VALVES INSTALLATION 15
10.0 FCCW TO FCW CONVERSION 16
11.0 ACTUATOR SIZING 17
12.0 DOUBLE ACTING ACTUATORS 17
13.0 SPRING RETURN ACTUATORS 17
14.0 ACTUATORS CICLE TIMES 18
15.0 SAFETY INSTRUCTIONS 19
16.0 DANGEROUS AREAS 19
WARRANTY INFORMATION 20
