Multi-point locks
General installation instruction
GU-SECURY Automatic Panik |SECURY 19 | SECURY 21
EN
. | G | Designed in Germany
With lip Without lip
Floor striker for
bottom locking
Striker for top
locking
Striker shapes for the top and bottom locking of the passive leaf
To install GU
multi-point
locks, use the
appropriate GU
factory drawing.
Undimensioned radii R = 
+
mm
Striker recess for SECURY multi-point locks
EN  EN 
Fig. 2: Approved striker shapes
40
40
13.5
13.5
40
0.6
13.5
0.6
40
40
40
13.5
13.5
13.5
1.1
1.1
40
40
11.4
11.4
1
1
Single-leaf
doors
Recess for top
latchbolt
Recess for
top latchbolt,
adjustable by
±mm
Recess for
central latch-
bolt
EN / EN
interchangeable
latch piece,
adjustable by
±mm
Recess for
bottom latch-
bolt
Recess for
bottom
latchbolt,
adjustable by
±mm
Double-leaf
doors
SECURY / GU-SECURY
Automatic Panic
or or
