G-U SECURY Automatic - Wire Diagrams - Option 5

Information in this document can be modified without notice.
Edition 07.2020..
Module Power Supply
Grey +V
White Ground
Module SC R
Green V
Blue 
SECURY Automatic european profile cylinder lock
Universal module = -C---
A-opener = K-C---
SECUREconnect  = K-C---
Faceplate for SECUREconnect = -C-XX--B
( required)
Automation system = by other
Potential-free contact = by other
Intercom = by other
Switch = by other
Access control = by other
Power supply = -C---
V AC, Hz
Door Multipoint Locking System
Solid brass handle & 45mm plate series
Wire Diagrams – Option 5
SECURY Automatic, A-opener, SECUREconnect , Universal Module, V DC
DOOR FRAME
DOOR LEAF
SECURY
Automatic
Lock
V DC
.A
Black = 
Grey = GS
Brown = VS
Door Multi-point Locking System  Automatic Smart Access Controlled
F
A-opener
A
C
Automation
hub
Smartphone with
automation app.
* Do not install the SECUREconnect if conditions require a higher protection class than IP 
F
R
Universal
module
(relay)
OPTIONAL
Smartphone with
Danalock app.
Term.: V(+) / G(-)
Power Supply
