18)
P18-Shift gears with gear
：
short press +
/ - to switch from 0
t
o 1; 0
：
Don't shift gears
；
1: Shift gears.
19) P19- Throttle the 6KM function
：
short press +
/ -
to switch
from 0 to 1; 0
：
Turn to the normal
；
1
：
Throttle 6Km
。
7. Specifications
1) Power supply: 24V,36V,48V
2) Rated current: 10mA
3) Max current: 30mA
4) Leakage current after power off: <1uA
5) Current supply to controller:50mA
6) Working Temperature
：
-18~65℃
7) Storage temperature
：
-30~80
℃
8. Error code definition
When an error appears, GD01 will notice users by different codes,
please refer to table 1 for different codes:
