Galanz GLW57MS2B16 User Manual

MOVING THE WINE COOLER
MOVING THE WINE COOLER
9
MOVING THE WINE COOLER
Excessive Weight Hazard
Use two or more people to move and install
wine cooler.
Failure to do so can result in back or other
injury.
WARNING
1. Turn off the wine cooler and unplug from the outlet.
2. Remove all wine and securely tape down all loose items
inside.
3. Tape the door shut.
4. Do not lift or pull the door or door handle during
transportation.
5. When moving, the appliance can not be tilted over 45
degrees as possible damage to the sealed system could occur.
6. Take care to avoid strong vibration or impact to the appliance.
REVERSING THE DOOR
1
2
Top hinge cover
Top hinge screw
3
4
5
6
Top hinge
Cabinet plug
Door seal
Handle screw
7
8
Door plug
Handle
Door handle plug
Baffle screw
9
10
Baffle
Bottom hinge screw
Bottom hinge
11
12
13
7
8
9
10
11
12
13
1
2
3
4
5
6

Galanz GLW57MS2B16 Specifications

General

Brand	Galanz
Model	GLW57MS2B16
Category	Kitchen Appliances
Language	English
