24.3.6.3. The menu item 'Terminal programming: Keep up & Exit'
Terminalprogr.:
Keep up & Exit
If you activate 'Mode' here you quit the menu of the terminal function
without having changed any parameter. Use this selection also if you want
to exit the menu of the terminal function after having made another
selection before, for example after having entered a programming.
24.3.6.4. The menu item 'Terminal programming: Edit'
Terminalprogr.:
Edit
If you activate 'Mode' here you will enter the menu for editing the terminal
function.
C: 1 T: ---s
D: 0.00s A:---
'C' stands for 'Cue', which is the firing channel.
'T' is the parameter duration ('T' for lat. tempus).
'D' stands for 'Delay', which is the step delay.
'A' stands for 'Atomic effect'.
After invoking this edit menu firing cue 1 is pre-selected. The double-headed arrow indicates which
parameter can be currently changed with 'Up' and 'Down'. After deletion of the memory no durations
are programmed at all. In this case '---' is being displayed for the duration and the atomic effect. '0.00'
is being displayed as a step delay.
If '---' is being displayed for the duration, this means that for this firing cue no flame will be generated
by this device.
Programming example:
- Firing cue 4 should generate a short flame ball with a duration of 0.3 seconds
- With cue 7 a flame column with a duration of 4.2 seconds should appear.
- Cue 12 should generate an atomic effect with a duration of 0.9 seconds and an atomic effect delay of
0.7 seconds.
- Cue 17 should trigger a short flame ball with a duration of 0.5 seconds and an atomic effect delay of
0.4 seconds. This flame effect is part of a step sequence and due to that a step delay of 1.47
seconds should be counted down before the effect will be generated.
C: 4 T: ---s
D: 0.00s A:---
As long as the double-headed arrow is being displayed next to the cue
number you can select the cue, in this example cue 4, which should be
assigned with a flame effect by activating 'Up' and 'Down'.
C: 4 T: ---s
D: 0.00s A:---
With each short activation of 'Mode' the double-headed arrow jumps to the
next parameter. So you have to activate 'Mode' once for a short time to
determine the firing duration.
C: 4 T: ---s
D: 0.00s A:---
Now you can enter the duration for this firing cue by activating 'Up' and
'Down'.
C: 4 T: 0.3s
D: 0.00s A:---
According to the programming example 0.3 seconds have been entered.
C: 5 T: ---s
D: 0.00s A:---
Activate 'Mode' three times for a short period to skip the parameters atomic
effect and step delay. Then you will have the opportunity to edit the
programming of the next cue. If the double-headed arrow jumps to the cue
number again the cue number will be incremented automatically.
C: 7 T: ---s
D: 0.00s A:---
Select cue number 7 by activating 'Up' two times for a short period.
C: 7 T: 4.2s
D: 0.00s A:---
Jump to the parameter duration by activating 'Mode' once for a short period
and enter the value 4.2 seconds with 'Up' and 'Down'.
