47
In the following chapter we will describe which messages are being displayed one after another. In
general first the selected control method is being displayed, followed by additional screens regarding
the operation status and settings.
28.1. Displayed information during receiving mode or respectively
ready to fire mode, that appears in all operation modes
28.1.1. Information which control method has been selected
Depending on the selected control variant one of the following screens is being displayed:
(PFC or PFS)
Input: Cable
(RS485 of PFC)
F:003
_
, S:012x
The programmed flame channel and safety channel is being displayed if DMX512 has been chosen as
an input ('F' = Flame channel, 'S' = Safety channel).
In addition the status of the safety channel or respectively of the DMX reception is being displayed. 'x'
means that either no signal is being received or that the value of the safety channel is not between
60% and 80% (= generation of flame effects is not enabled).
'' after the safety channel indicated that a DMX signal is being received and that a value between
60% and 80% is being received for the safety channel (= device armed).
This example shows the display content if the device is armed by the safety
channel (noticeable by the '' after the safety channel) and if the flame
channel has activated a flame effect (flame symbol next to the flame
channel).
28.1.2. Tilt switch on/off and its status
Status: OK
In general it is being displayed if the tilt switch has been enabled or not and
the status of the tilt switch. The tilt switch is enabled in this example, i.e. the
flame effect will be terminated if already in progress or flame effects will be
disabled if the device is tilted by more than 45°. Status OK means that the
G-Flame is not tilted by more than 45° and the generation of flame effects is
enabled.
Tilt Switch: On
Status: >45°
Here the device is tilted by more than 45° and flame effects will be
terminated if this condition is detected during a flame effect and the fuel
valves will remain closed if the tilt angle is exceeded in the moment of
triggering an effect.
Tilt Switch: Off
Status: >45°
The tilt switch has been turned off in the menu. The G-Flame will ignore a
tilt angle of more than 45° and flames will be generated, no matter how
much the device is being tilted.
