6
Chapter 4: Board System
Printhead Board
Main Board
Encoder sensor
Magnetic sensor
Processing
Indication
Optical Fiber plug
Printhead cable
plug 1
Power flat
cable plug
Status LED
Power LED
Printhead cable
plug 2
Power cable Plug
Pump plug
Power supply
plug
USB
线接口
Processing Indication
Optical Fiber plug
Status LED
Power LED
Control panel plug
