CHAPTER 1 SPECIFICATIONS
GENERAL
Model
Frequency Range 28.315 ~ 28.755 MHz
Emission FM/AM/USB/LSB
Frequency Control Phase-Lock-Loop (PLL) Synthesizer
Frequency Stability 0.001%
Temperature Range
-30°Cto+50°C
Antenna Impedance 50 Ohms
Antenna Connectors Standard SO-239 type
Input Voltage 13.8V DC
Size
73/4"(W)x27/8"(H)x101/4"(D)
Weight
6lb.
TRANSMITTER
AM/FM: 2W~50WRF Power Output
USB/LSB: 150W PEP
Spurious Emission -50 dB
Unwanted Sideband -50 dB
Audio Distortion 10%
Frequency Response 300 to 2500Hz
Microphone Dynamic
Clarifier Range
Coarse: ± 6.0KHz, Fine: ± 1.0KHz
RECEIVER
Sensitivity for 10 dB (S+N)/N AM: < 0.5 μV; USB/LSB: < 0.25 μV
Sensitivity for 12 dB (S+N)/N FM: < 0.25 μV
Squelch Sensitivity < 0.5 uV
Selectivity -55
Image Rejection -50 dB
AGC Figure of Merit 100 mV for 10dB Change in Audio Output
Audio Power Output 2.5W @ 10% Distortion
Audio Response 300 to 2500 Hz
(SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
DX95T2
