9
Rear Assembly
Galaxy S21 FE has a Rear Assembly that is broken down into
three (3) Pieces:
The Top/Middle Pieces contain:
• Receiver
• Near Field Communication (NFC) and Wireless Charging
(WC) Pad
• NFC Flex Connector
The Bottom Piece contain:
• Main Antenna
• Speaker
The rounded pads on the Bottom Piece allow for the Speaker to
make contact with the Sub PBA for sound while the rounded
pads on top piece allow for the Receiver to make contact with
the Main PBA.
Inner Outer
