Installing the Battery
• Use and place the 0.6N Torque Wheel
on the Press Jig base; remove the film
from the new Battery and attach it to
the OCTA from top to bottom
• Place the device face down on the
large Battery Press Pad
• Place the smaller Battery Press Pad
on top of the Battery
• Insert the device in the Press Jig and
spin the Torque Wheel until it torques;
wait five (5) seconds before
unspinning and removing the device
Press Jig Universal Press Pads
