Gallagher 3E3084 M1800i M2800i 110v Energizer User Manual
9
UNDERSTANDING YOUR M1800i/ M2800i
ENERGIZER CONTROLLER
Current Display
Shows the amount of load on the
energizer / fence zones
Voltage Display
Shows energizer / earth / fence zones voltage
Status LED
Provides quick
indica on of the
fence status
Zone
Indicators
Displays which
energizer /
earth zones are
opera ng and if
they are in alarm
Se ngs bu ons
Change alarm levels and
energizer output voltage
Standby bu on
Turns the energizer pulses
on and off
Naviga on Bu ons
View energizer / earth zones
to see zone performance
Quickscan
Bargraph
Gives fast visual
indica on of fence
voltage
Zone Indica on
Arrow
Highlights which
energizer / earth
zone is being shown
on the main display
Status LED
Green The energizer and fence are opera ng normally
Red The energizer has detected a fault. Check the LCD screen to
determine where the problem is.
Flashing Red The energizer output voltage is low.
Quickscan Bargraph
The Quickscan bargraph gives quick visual indica on of the energizer output voltage.
Each bar illuminated represents approximately 1KV output.
Green Segments Your fence is performing well. No a en on is required.
Yellow Segments Your fence is under some load but is s ll delivering an
eff ec ve shock.
Red Segments Your fence is under heavy load and requires maintenance.
