Gallagher 3E3084 M1800i M2800i 110v Energizer User Manual
7
Step 3. Connect the fence
a) Connect the energizer’s red output ( ) terminal to the fence using
Underground Cable (G627). Remove 5cm (2”) of plas c coa ng from one end
of the cable. Unscrew the red (FENCE) terminal and insert the wire through the
terminal slot. Screw the terminal closed, ensuring the wire is fi rmly clamped.
b) A ach the other end of the cable to the fence using a Joint Clamp (G603).
For instruc ons on fence installa on see the Gallagher Power Fence™ Manual or go
to www.gallagher.com.
Step 4. Turn the Energizer On
a) Plug the energizer into a power outlet.
b) Check that the Power On LED on the front of the energizer is green.
c) Re-a
ach the orange terminal cover.
IMPORTANT: Readings will change as the fence condi ons change. This is the
Energizer monitoring the fence and Energizer performance. Read the sec on
“Understanding your M1800i / M2800i Energizer Controller” (p.10) for a complete
understanding of the display and alarms.
