Galletti LCA 080 - Page 33

LCA
RG66000986 – Rev.00
33
HMI
480
4296
70
511
1635
1160 810 175
1654
1637
4366
324 999 324
Baricentro con serbatoio vuoto
1600
9
5
6
Fronte unità Front unit
Laterale Side view
Retro Rear view
1
2
Vista dall'alto Top view
3
Center of gravity with empty tank
1 Water inlet (2" gas) 2 Water outlet (2" gas) 3 Power supply input 4 Electric control board 5 Refrigerant pressure gauges (optional) 6 Advanced control microprocessor (optional) 7 pump system (optional) 8 Inertial storage reservoir (optional) 9 Condenser protection grilles (optional)
LCA 205 – 220 – 235 LCA 180 CL
