Galletti LCA 080 - Water Pumping and Storage Systems

LCA
RG66000986 – Rev.00
35
14.3 WATER PUMPING AND STORAGE SYSTEMS
LCA units may be equipped with 4 types of pumping systems, complete with expansion tank, and inertial
storage reservoirs:
- single standard pump
- single uprated pump
- standard pump and back-up pump
- uprated pump and back-up pump.
In the case of pump systems including a back-up pump, the microprocessor controls the pumps in such a
way as to equally divide the hours of operation, changing over the pumps in the event of a fault.
14.4 WATER PUMPING AND STORAGE SYSTEMS
LCA units may be equipped with 4 types of pumping systems, complete with expansion tank, and inertial
storage reservoirs:
- single standard pump
- single uprated pump
- standard pump and back-up pump
- uprated pump and back-up pump.
In the case of pump systems including a back-up pump, the microprocessor controls the pumps in such a
way as to equally divide the hours of operation, changing over the pumps in the event of a fault.
LCA 045 050 060 070 080 090
Standard pump type A A B B B C
Available head, LCA with standard pump (nominal flow rate) kPa 79 74 123 117 116 159
Rated electrical output, standard pump kW 0,55 0,55 0,75 0,75 0,75 1,50
Operating current, standard pump A 1,7 1,7 2,3 2,3 2,3 4,3
Uprated pump type kW C C D D D E
Available head, LCA with uprated pump (nominal flow rate) kPa 183 178 138 224 221 229
Rated electrical output, uprated pump kW 1,50 1,50 2,20 2,20 2,20 3,00
Operating current, uprated pump A 4,3 4,3 5,3 5,3 5,3 6,6
Inertial storage reservoir capacity dm
3
218 218 315 315 315 485
Expansion tank dm
3
8 8 8 8 8 12
LCA 115 130 150 180 205 220
Standard pump type C C D D E E
Available head, LCA with standard pump (nominal flow rate) kPa 131 126 143 138 146 139
Rated electrical output, standard pump kW 1,50 1,50 2,20 2,20 3,00 3,00
Operating current, standard pump A 4,3 4,3 5,3 5,3 6,6 6,6
Uprated pump type (see diagram) kW F F F G G G
Available head, LCA with uprated pump (nominal flow rate) kPa 264 258 238 279 281 278
Rated electrical output, uprated pump kW 4,00 4,00 4,00 7,50 7,50 7,50
Operating current, uprated pump A 9,6 9,6 9,6 16,0 16,0 16,0
Inertial storage reservoir capacity dm
3
600 600 600 600 850 850
Expansion tank dm
3
20 20 20 20 20 20
