4. PARTS LIST/REFERENCE (some parts may be pre-assembled)
Before starting installation, check to make sure all parts are present in package. Parts listed as description (quantity)
Pump, Strainer Housing, Basket & Lid (1) Pump, Strainer Basket & Lid (1) Filter tank (1)
(only model 35D, item 4706, shown assembled) (shown assembled)
4 Way Valve (1) Manifold (1) Base Plate (1)
Filter Drain Plug Assembly (1) Flange Clamp (1) Tank Large O-Ring (1)
Hose Clamp & Tip (2) Hose Adapter (5) Hose Adapter O-Ring (3)
Waste (Backwash) Plug (1) Short Intex adapter (2) Short Intex Adapter Gasket (2)
Sand Shield (1) 1¼" (32mm) Hose (1) Pressure Gauge (1)
Pressure Gauge Plug (1) Pump Mount Screw & Washer (4) Flange Screw & Nut (2) Pump Drain Plug & Gasket (1)
Note: Some parts may be pre-installed at the factory. Parts not shown to scale.
