7

How to install the water cooling

Put the radiator in top place

Put the radiator in front placePut the radiator in the rear

panel then fix with screws

Fix with screws

Fix with screws

Front panel : 240/360mm

Top panel: 280/360mm

Rear panel: 120mm

The size of water-cooling:
