GAMEMAX MASTER 2 - Hardware List

Combo Audio Micphone
Combo Audio
Type-C Gen2
Power SW
Hardware List
Hardwareliste / Lista de hardware / Список оборудования / 零件清单
I/O Panel
I/O Panel / N/O Panel / Painel de N/O / Панель N/O / I/O面板
USB 3.0USB 2.0
POWER SW
x17 x13 x16
Screws
for Motherboard
Screws
for PSU Mounting
Screws
for 3.5” SSD Mounting
a
b
c
x3
1
MASTER 2
d
Type C Gen2
A1 GND
A2 TX1+
A3 TX1-
A4 VBUS
A5 CC
A6 D+
A7 D-
A8 SBU1
A9 VBUS
A10 RX2-
A11 RX2+
A12 GND
GND B12
RX1+ B11
RX1- B10
VBUS B9
SBU2 B8
/ B7
/ B6
VCONN B5
VBUS B4
TX2- B3
TX2+ B2
GND B1
Fan Controller(Low-Stop-High) Fan Controller(Low-Stop-High)
Power SW Reset SWUSB 2.0 USB 3.0
M/B Standoff
