POWER SUPPLY AND COMMUNICATION CONNECTIONS (J101)
Ref.No
Abbr.
Name
Notes
1
PWR
12VAC / 12VDC (Board power supply)
2
PWR
12VAC / 12VDC (Board power supply)
3
GND
0V
4
GND
0V
5
V+
12V
232
232
RS232 Serial
FC10
6
CANL
CAN Communication
7
CANH
CAN Communication
EXP
Keyb.IF
Remote keyboard interface
FC20
11
In.Com
Common for digital inputs
12
In.0
Doser pedal
13
In.1
Mixer thermal protection
14
In.2
Auger thermal protection
15
In.3
Refrigerator thermal protection
16
In.4
Door micro
17
In.5
N.C.
18
In.6
N.C.
19
In.7
N.C.
WARNING: digital inputs must be powered by voltage ranging between 12 and 24 Volts (AC/DC).
The board does not drive any inputs which must therefore use an external source of power.
21
Snd1-1
Red PT100 Tank
22
Snd1-2
Red PT100 Auger resistor
23
Snd1-3
White PT100 Tank and Auger Resistor
24
Snd2-1
White PT100 Tempering
25
Snd2-2
Red PT100 Tempering
26
Snd2-3
Red PT100 Tempering
27
Snd3-1
N.C.
28
Snd3-2
N.C.
29
Snd3-3
N.C.
30-31
Out.0
Tank resistor
32-33
Out.1
Refrigerator
34-35
Out.2
Mixer Motor
36-37
Out.3
Auger Motor
38-39
Out.4
Vibrating table vibrator
40-41
Out.5
Vibrating table resistor
42-43
Out.6
Water pump
44-45
Out.7
Auger resistor
WARNING: all relay outputs are with pure NO contact
