MBFS11 BADM FRAME SUPPORT
MBMSS11 BADM MOUNTING SYS UPG
MBFC BADM FLOATING CLAMP
MDCSC BADM FIXED CLAMP
MPG STARTING CLAMP
MPMC MACHINE COVER
MPS CLEANING STONE
MPXFS FLOOR STAND
SGSM STRINGER’S MAT
PARTS LIST
4A TURNTABLE BUSHING
5 RUBBER FOOT
6A CAP SCREW
8 BUSHING SET SCREW
9 WASHER- M8
10B WINDER STAND
14 WASHER- M10
21A FRAME SUPPORT SLIDE
25 TENSION BAR
26 TENSION BAR CAP
27 DROP WEIGHT KNOB
28 FRONT WEIGHT- BADMINTON
29 BACK WEIGHT
30 TENSION BAR DRUM
30A SET SCREW
31 STRING GRIPPER DRUM
34 RATCHET TEETH
35 RATCHET TEETH SPRING
83 TENSION BAR STOP SCREW
133 FRAME SUPP SLIDE SCREW
140 MTNG STAND TOP PLATE
141 MTNG STAND TOP PAD
144 SHLDER SUPP LOCK KNOB
146A SUPP ARM ADJUST KNOB
161 WINDER BEARING
162 GRIPPER PIVOT PIN
163 PIVOT PIN RETAINING COLLAR
187 PII BASE
188 PII BASE COVER
189 PII LOWER TRAY PAD
190 PII UPPER TRAY PAD
261 TT END CAP
262 SUPP POST MOUNTING PLATE
271 SUPPORT POST
356 QM ARM (LONG) RIGHT
357 QM ARM (LONG) LEFT
381 SHOULDER V-MOUNT
71 6MM T-AHNDLE HEX WRENCH
98 10MM WRENCH*
108 UTILITY KNIFE*
109 NEEDLE NOSE PLIERS*
110 BENT NOSE PLIERS*
196 17MM SOCKET*
251 HEX WRENCH SET*
MA STRINGER’S AWL*
MPSA PATHFINDER AWL*
MFSPP11 FRAME SUPP PADS
SHORT BADMINTON (SB)
SQUASH (SQ)
TENNIS (T)
BADMINTON (B)
MMSPP13 TENNIS SHOULDER SUPP PAD
MBMSP11 BADM SHOULDER SUPP COVER
* (NOT SHOWN)
OPTIONAL TOOLS & ACCESS
PART # DESCRIPTION
TOOLS & ACCESSORIES
MPFC FLOATING CLAMP
MRSG ROTATIONAL GRIPPER
PART # DESCRIPTION
