Computer module »DP-HR-CPU-MC2-UC«
21 · Computer and console modules (DP-HR)
Computer module
»DP-HR-CPU-MC2-UC«
With DP-HR-CPU-MC2 computer modules, you can connect a computer with Display-
Port graphics outputs (dual-head) to two different digital matrix switches of the Control-
Center-Compact or ControlCenter-Digital series.
At the consoles of both matrix switches, users can access a computer module to
operate the connected computer.
Package contents
 1 × Computer module DP-HR-CPU-MC2-UC
 2 × DisplayPort video cable (DP-Cable-M/M-2)
 1 × USB device cable
 2 × Audio cable
 1 × Power pack (12V/2A, only with variants incl. PowerPack)
 1 × Power cable (only with variants incl. PowerPack)
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
Required accessories
 4 × Category 5e (or better) twisted pair cables to connect the computer module to
two different matrix switches
IMPORTANT: Only consoles configured for multi-monitor operation via channel
grouping can show the images of both of the computer’s video outputs on separate
monitors.
At consoles with one monitor only, the image of the computer’s second video out-
put is not displayed.
