IIDTool

Legend of controls for the Integrated Interface

Selectable icons Navigation Role Entering Role Equivalent Action :

Menu up Increase the value

Menu down Decrease the value

Back or exit a menu Cancel action Escape

Scroll through the options available

in a menu

Validate an action or

Select

Enter

Table 1. Legend of controls for the Integrated Interface replica

Integrated Interface display

The display is on the dashboard screen in all cases.

Dashboard screens have a limit of visible characters. If a longer message needs to be displayed (eg.

a fault descriptor), it will automatically scroll in order to allow full read.

Range Rover 2002 to 2005:Ifareadingdi󰀩cultyrelatedtomissingpixelsispresent,itispossible,at

speciclocations,toscrollinformationfromlefttoright(eg.Activationcode)usingthecontrols or .
