GAPOSA QCXSUN - Additional Transmitter Functions; Transmitter Command Functions; Battery Replacement; Battery Replacement Guide

4. ADDITIONAL FUNCTIONS (AS A NORMAL TRANSMITTER)
Buttons 1+2= opening command to programmed blinds/shutter;
Buttons 2+3 = closing command to programmed blinds/shutters.
5. REPLACING THE BATTERY
1. Remove the rubber band, the screw and the back cover;
IMPORTANT: While replacing the battery, it is extremely important to be very careful
and to not damage the sun sensor.
2. Take out the electronic board and remove the battery;
3. Position the battery (CR2450) according to polarity;
4. Reinstall the back cover, the screw and the rubber band.
OPEN
1 2
3
CLOSE
check polarity
IMPORTANT: While
replacing the battery, it
is extremely important
to be very careful and
to not damage the sun
sensor.
rear
