B. Events
The PP420 can send out UDP or TCP messages on certain events. See the GT command to see
how to enable/disable Ethernet messages.
The messages are of the form:
Evt c,m
Where:
c = output channel (1, 2, 3, 4) or 0 for general messages
m = event number
Event number Reason
128 A light has been detected and the controller is waiting for the current rating
to be entered.
129 A light has been detected. The current rating is not required.
130 Temperature error. The PP420 is too hot and has switched off to protect
itself.
131 Too much current. More current is being output than should be, so the
PP420 has turned off the outputs. This may be caused by a hardware error.
