Adaptor for G 3/4 thread (26.5 mm)
The adaptor supplied allows the Water Timer to be connected to taps with
a G 3/4 thread (26.5 mm). If you are using the adaptor, screw the adaptor
onto the tap before screwing the Water Timer onto the adaptor.
Warning! Attach and screw on manually. Do not use pliers!
6.3 Function Keys and Display (Fig. C)
Not
e: The Water Timer control unit
1
can be removed (Fig. B). This allows
you to set the watering program somewhere other than where the Water
Timer is to be used.
Menu-O.K.
➔ Changes to the next stage of the program. Simultaneously accepts
and confirms the data you have entered using the man. key.
On/Off-man.
➔ Used to change the individual data (e.g. counting hours, minutes, ...)
➔ To switch a connected watering system on and off manually.
LCD Display
Note:
.
In the entry mode the corresponding display flashes.
.
At high temperatures (over 60 °C at the display) the LCD may extinguish.
This has no effect on the program sequence. Once the LCD display
cools down, the display will appear again.
On
Status display – The connected watering system is active.
Off
Status display – The connected watering system is inactive.
Time (current time)
➔ In the programming mode: Hours – Hours of the current time
Minutes – Minutes of the current time
Start
➔ Starting time; when the watering system becomes active.
Hours – Hour when devices become active
Minutes – Minutes when devices become active
Cycle
Displays selected program.
35
