18
EN
The display level can be changed at any time by pressing the
Menu button. All programme data changed up to this time and
confirmed with the OK button is saved. If data is changed during
programmed irrigation and confirmed with the OK button then
the valve is closed.
Display Description
5
Weekdays Current weekday or programmed
Mo , Tu , ... watering days
S
.
6
Time Current time of day (flashes when in
input mode).
7
am / pm Display for 12-hour clock (e.g. in USA,
Canada).
8
Start Watering start time (flashes when in
input mode).
9
Run Time Watering duration (flashes when in
input mode).
0
8h, 12h, 24h, Watering cycle (with activated).
2nd, 3rd, 7th Every 8 / 12 / 24 hours; every 2nd / 3rd /
7th day.
A
Prog
ON
/
OFF
Watering programme on (
ON
) / off (
OFF
).
B
Direct sensor Watering is automatically controlled
control between 20:00 and 06:00 via the Soil
Moisture Sensor.
C
Sensor 1 / 2 Dry sensor dry : watering is carried out.
dry / wet Wet sensor wet: watering is not carried
out.
D
Valve
ï
V1 / The arrow indicates the selected valve:
Valve V2
ð
-
displayed
S
: the valve is connected
-
flashing
S
: the valve is open
E
Battery Indicates 5 battery levels:
3 bars: Battery fully charged
2 bars: Battery half full
1 bar: Battery low
0 bar: Battery almost flat
Frame
is flashing: Battery flat
If the battery frame is flashing, the valve is no longer opened. A
valve opened by the programme will also close again if the
battery is flat. The battery display is reset when the battery is
changed.
D
E
C
A
7
5
9 8
C
6
0
B
D
Display messages:
