5. MAINTENANCE v (Fig. E)
– During normal operation, the currently measured
level is displayed constantly.
– The switching point as of which the sensor sig-
nals that the soil is moist – thereby preventing
watering – is selected via the number of levels.
– 0 dots for loamy soil
v Sensor response when soil is quite dry.
– 3 dots for sandy soil
v Sensor response when soil is very moist.
Soil Moisture Sensor, Art. 1188,
(optionally available,
models up to 2020)
The soil moisture level at which a watering
will not be carried out as per the schedule
can be set using the switching point controller on
the soil moisture sensor (see GARDENA Soil Mois-
ture Sensor Operator’s manual).
Fig. J:
1 Active watering | 2 Change watering duration |
3 Stop active watering at any time
By pressing the button, manual watering
can be started or stopped at a desired time.
A duration of between 1 minute and 59 minutes
can be selected.
6. STORAGE
To put into storage:
v The product must be stored away from
children.
v To preserve the battery, it should be removed
(fig. B).
v Store the controller and the valve unit in a dry,
enclosed and frost-free place.
Disposal: (in accordance with RL2012/19/EC)
The product must not be disposed of to
normal household waste. It must be dis-
posed of in line with local environmental
regulations.
IMPORTANT!
Dispose of the product through or via your
municipal recycling collection centre.
Disposal of the battery:
v Please return a flat battery to a GARDENA dealer
or dispose of it properly at your nearest recycling
centre.
Dispose of the battery only when discharged.
EN
16
