Gardena Smart Irrigation Control - Connecting Valves to Valve Box

To connect the valves to the Valve Box:
Make sure that the terminal block has been correctly installed in the
valve box.
!
123456CCCC
V1 V2 V3
(ART. 1278) (ART. 1278) (ART. 1278)
v Label the valves (1 – 6) with the yellow stickers of the valve box.
(Therefore the signal cable terminals VALVES 1 – 6 of the Irrigation Control
can be clearly assigned to the valves).
