Position Description No.
409725 Sprocket wheel 1 till 3
409726 Oiler cap 8
409727 Spring 9-2
409728 Gear (set) 9-5 + 23-6
409729 Gripping teeth 10
501534 Insert plate 15
409737 Chain tension adjustment 16 + 18
409730 Rotor 23-9
409731 Carbon brush holder 23-19
409732 Carbon brush (set) 23-20
409733 Carbon brush cap 23-21 + 23-22
409735 Switch + button 29 +34
409734 Switch junction rod 35
409736 Micro switch 36
409738 Guard 49
KZA1004 Chain guide bar, 40 cm 64
KZA1005 Saw chain, 40 cm 65
501543 Chain bar cover 66
HELPLINE No. UK 0905-1460005
(£ 0,06/min)
• IRELAND 1520-932626
(E 0,15/min)
WEB SUPPORT: www.heltec.eu
Model Number: GCS-2000
39
Parts list
8
Safety features
Numbers preceding the descriptions correspond with the numbers above to
help you locate the safety feature.
3 Trigger start / stop switch
Stops saw motor when released.
9 Chain brake lever / hand guard
Activates the chain brake and protects the operator’s left hand in the event
it slips of
f the front handle while saw is running.
7 Electric motor
Is double insulated for added safety.
10 Lock / off button
Prevents accidental acceleration of the saw motor. The trigger cannot be
squeezed unless lock/of
f button is pushed forward to end.
13 Low-kickback chain
helps significantly reduce kickback, or the intensity of kickback, due to
specially designed depth gauges and Guard links.
19 Chain catcher
---
Machine data
HELPLINE No. UK 0905-1460005
(£ 0,06/min)
• IRELAND 1520-932626
(E 0,15/min)
WEB SUPPORT: www.heltec.eu
Model Number: GCS-2000
