6Operation
Important! Always switch the appliance off and un-
plug the power plug before making any adjustments.
6.1 Insert the chain that is to be sharpened into the
chain bar (Fig. 7)
To do this, loosen the chain locking screw (6)
6.2 Set the grinding angle according to the specifica-
tions for your chain (Fig. 8) (normally between 30-
35º)
• Slacken the locking screw for setting the grinding
angle (4)
• Set the desired grinding angle using the scale (3)
• Tighten the locking screw (4) again
7 8
6
3
4
