SUTORBILT LEGEND SERIES BLOWERS
MATRIX/MENU
NOTICE TO CUSTOMER – To find the construction options for
Your blower unit, FILL IN THE BALANCE OF LETTERS OR G A P
NUMBERS FROM YOUR UNIT NAMEPLATE __ __ __ __ __ __ __
COLUMN NUMBER: 1 2 3 4 5 6 7
FOLLOW THE LINE DOWN AND OVER FROM EACH SPACE
THUS FILLED IN TO FIND THE APPROPRICATE
CONSTRUCTION OPTION WITH WHICH YOUR MACHINE IS
EQUIPPED.
COLUMN 1 – BASIC DESIGNATOR
COLUMN 2 – PRODUCT FAMILY
COLUMN 3
–
GEAR DIAMETER
F 6”
G
7”
H
8”
COLUMN 4 – CASE LENGTH
L - Low Pressure
M - Medium Pressure
H - High Pressure
COLUMN 5
–
CONFIGURATION
A Vertical-Top Hand -Central Timed
B Vertical-Bottom Hand – Central Timed
C Horizontal – Left Hand – Central Timed
D Horizontal – Right Hand – Central Timed
COLUMN 6 – DESIGN VERSION
COLUMN 7
–
ADDITIONAL DESCRIPTION
A. Lip Seal
B. Mechanical Seal

Gardner Denver LEGEND P Series Specifications

General

Brand	Gardner Denver
Model	LEGEND P Series
Category	Blower
Language	English
