GARLAND HALF SIZE ELECTRIC CONVECTION OVEN MODEL MCOE5L INSTALLATION/OPERATION MANUAL
Part # 4516833 Rev A (20 Sep 2011)
Page 15
PARTS ID: OVEN EXTERIOR; ALL MODELS
Item Part # Description
1 1960901 Main Top MCOE5L
2 1960902 Cover, Micro Switch Access
3 1960502 Flue Box MCOE5
4 1961199 Partition Side Assembly
5 1671101 Fan - 110MM, 208/240 V
6 1951402 Body Side, CNTRL
7 CK1385497 Hinge Bracket Assembly
8 1011201 Steel Tubing Chrome Spacer
9 1951401 Body Side, Oven
10 1960709 Ba e MTG BRKT
11 1766001 Oven Rack
12 1966503 Door Seal MCOE5
13 1766004 Rack Guide
14 1962199 Oven Door MCOE5
15 1966501 Door Seal RT Silicon
16 1966502 Door Seal Top / Bottom Silicon
17
CK1765199 Element Assembly - 208 Volts
CK1765198 Element Assembly - 240 Volts
18 1960797 Ba e Assembly
19
1946673 Control Panel Assembly - USA
1946673-1 Control Panel Assembly - Canada
20 1962299 Card Reader Assembly
21 4519657 Blower Wheel Assembly Includes Wheel Puller, Spacers & Fasteners
22 1951502 Motor 208-240 1/3 HP 5/8 Shaft
23 1027801 Swivel Caster with wheel lock
24 1027800 Swivel Caster W/O lock
25 1028500 3/8 x 90 BX Connector
26 1960504 BX Cable 15 3/8”
27 1960503 High Limit Cover
28 4520416 High Limit 135C Degree (275 F)
29 1028501 3/8 BX connector
30 CK1962196 Micro Switch Bracket Assembly Complete
31 9006401 Switch-Mini Snap Hi-Temp 1 Amp.
32 8003221 4-40x1 PH Pan HD M/S ZC
33 8001505 4-40 Keps Nut ZC
34 1750501 Door Catch
35A CK4529043 Plug and Cord, 208/240V -3Ph 30Amp, Pin and Sleeve
35B 1834503 Plug - Only - 30Amp
35C 1966411 Plug - Only (Hubbell) - 30Amp
36 4513157 Fuse (600V / 10A)
37 1774101 Fuse Holder
41 1910901 Hi Limit Bracket
