Garmin Fusion BB100 - Stereo Information; Specifications

Stereo Information
Specifications
Specification Measurement
Dimensions (black box stereo) (W × H × D)
Approximately 155mm (6.10in.) × 60mm (2.63in.)
× 94mm (3.70in.)
Water resistance (black box stereo) IEC 60529 IPX3
Water resistance (remote control) IEC 60529 IPX7 (front), IEC 60529 IPX3 (rear)
Operating temperature From 0 to 50°C (from 32 to 122°F)
Storage temperature From -20 to 70°C (from -4 to 158°F)
Input voltage From 10.8 to 16Vdc negative ground
Fuse rating 15A
NMEA 2000 LEN 1 (50mA)
ANT
®
wireless range Up to 3m (10ft.)
Compass-safe distance 15cm (5.91in.)
Pre-output voltage 3V peak
Current (standby) less than 15mA
Current (max.) 15A
Output music power per channel 50W
Total output music power 200W
Speaker impedance 4Ohm per channel
Total harmonic distortion (1W output, 4ohm load, from
20Hz to 20kHz)
0.04 typical
Less than 0.1% max.
Tuner
Europe and
Australasia
USA Japan
FM radio frequency
range
87.5 to 108MHz 87.5 to 107.9MHz 76 to 95MHz
FM frequency step 50kHz 200kHz 50kHz
AM radio frequency
range
522 to 1620kHz 530 to 1,710kHz 522 to 1,620kHz
AM frequency step 9kHz 10kHz 9kHz
Fusion BB100 Installation Instructions 9
