190-01878-02 GMA 342/345 Installation Manual
Revision 5 Page B-3
APPENDIX B OUTLINE AND INSTALLATION DRAWINGS
Figure B-3 GMA 342/345 Panel Cutout Drawing
6.30 160.0
1.30 33.0
1.20 30.5
6.30 160.0
6.18 157.0
OPTION 2:
FROM BACK OF AIRCRAFT PANEL
RADIO CUTOUT (RACK INSTALLED
THICKNESS IS .125 INCH [3.2 mm]
ONLY) MAXIMUM AIRCRAFT PANEL
OPTION 3:
FROM FRONT OF AIRCRAFT PANEL)
OPTION 1:
STACK CUTOUT (RACK INSTALLED
RADIO CUTOUT (RACK INSTALLED
FROM FRONT OF AIRCRAFT PANEL)
NOTES:
1. DIMENSIONS: INCH [mm]
2. IF THE FRONT LIP OF THE
MOUNTING RACK IS BEHIND
THE SURFACE OF THE AIRCRAFT
PANEL THE UNIT CONNECTORS
MAY NOT FULLY ENGAGE.

Garmin GMA 345 Specifications

General

Display Type	LCD
Audio Channels	6
Bluetooth	Yes
3D Audio	Yes
Marker Beacon Receiver	Yes
Voltage	14/28 VDC
Intercom Positions	6
Weight	1.6 lbs
Interfaces	RS-232
Audio Outputs	2 stereo, 4 mono
Audio Input	Music
