GPSMAP 9x3
Dimensions (W × H × D) 233.0 × 162.3 × 75.8mm (9
3
/
16
× 6
3
/
8
× 3in.)
Dimensions with cover on bail mount (W × H × D) 256.2 × 178.1 ×104.7mm (10
1
/
16
x 7 x 4
1
/
8
in.)
Clearance to next obstruction behind chartplotter 33.2mm (1
5
/
8
in.)
Display size (W × H)
198.7 × 111.8mm (7
13
/
16
× 4
3
/
8
in.)
22.9cm (9.0in.) diagonal
Display resolution WXGA, 1280 ×720 pixels
Weight 1.6kg (3.6lb.)
Compass-safe distance 30cm (11.81in.)
Wireless frequency 2.4GHz @ 18.3dBm maximum
Max. power usage at 10Vdc
Non-sonar models: 22.0W
Sonar models: 40.2W
Typical current draw at 12Vdc
Non-sonar models: 1.34A
Sonar models: 1.37A
Max. current draw at 12Vdc
Non-sonar models: 1.78A
Sonar models: 3.20A
Fuse 6A, 125V fast-acting
GPSMAP 12x3
Dimensions (W × H × D) 308.3 × 227.6 × 81.8mm (12
1
/
8
× 8
15
/
16
× 3
1
/
4
in.)
Dimensions with cover on bail mount (W × H × D) 327.2 × 246.3 × 113.8mm (12
7
/
8
× 9
11
/
16
× 4
1
/
2
in.)
Clearance to next obstruction behind chartplotter 18.7mm (
3
/
4
in.)
Display size (W × H)
262.1 × 164.2mm (10
15
/
16
× 6
7
/
16
in.)
30.7cm (12.1in.) diagonal
Display resolution WXGA, 1280 × 800 pixels
Weight 3.0kg (6.6lb.)
Compass-safe distance 45cm (17.72in.)
Wireless frequency 2.4GHz @ 18.3dBm maximum
Max. power usage at 10Vdc
Non-sonar models: 26.5W
Sonar models: 43.0W
Typical current draw at 12Vdc
Non-sonar models: 1.67A
Sonar models: 1.68A
Max. current draw at 12Vdc
Non-sonar models: 2.15A
Sonar models: 3.56A
Fuse 6A, 125V fast-acting
